Olympus E-510 Infrared Performance

We test the E-510 for infrared photography performance with the Hoya R72 filter.
The E-510 is a handy and compact camera. Also common to all the Olympus dSLRs we have tried, it actually has a Live View that works reasonably well in infrared (you just have to put it in Live View Boost mode from the menu).

Full sun exposure with the Hoya R72 filter lies at 100ISO, f3.5 and between 8 seconds and 2 seconds depending on which color channel you are aiming the exposure at.

Infrared photography with the Olympus E-510 digital camera

The following histograms show the channel results at differing full sun exposures (100ISO f3.5):

8 seconds
infrared photography tests

15 seconds
infrared photography tests

30 seconds
infrared photography tests
Now with appropriate RAW processing you can pull back much of the over exposure.

In extended testing I found the noise to be very well controlled at all ISO settings, though of course it is lowest at 100ISO.

The images below are a 100% section:
100ISO
Infrared photography with the Olympus E-510 digital camera

red
Infrared photography with the Olympus E-510 digital camera

green
Infrared photography with the Olympus E-510 digital camera

blue
Infrared photography with the Olympus E-510 digital camera

200ISO
Infrared photography with the Olympus E-510 digital camera

400ISO
Infrared photography with the Olympus E-510 digital camera

red
Infrared photography with the Olympus E-510 digital camera

green
Infrared photography with the Olympus E-510 digital camera

blue
Infrared photography with the Olympus E-510 digital camera

800ISO
Infrared photography with the Olympus E-510 digital camera

1600ISO
Infrared photography with the Olympus E-510 digital camera

red
Infrared photography with the Olympus E-510 digital camera

green
Infrared photography with the Olympus E-510 digital camera

blue
Infrared photography with the Olympus E-510 digital camera

You can treat the images in various ways with this camera, depending on the exact exposure you give. If you are careful to not over expose the red channel, then if you do levels on each individual channel the result can be a lovely false color image. You can also go to monochrome using one or more of the channels, again depending on the exposure.

Infrared photography with the Olympus E-510 digital camera

Infrared photography with the Olympus E-510 digital camera

Infrared photography with the Olympus E-510 digital camera

Red only
Infrared photography with the Olympus E-510 digital camera

Green only
Infra
red photography with the Olympus E-510 digital camera

Blue only
Infrared photography with the Olympus E-510 digital camera

The two images below show the center of the image after processing from a single channel:

Infrared photography with the Olympus E-510 digital camera
Green Channel

Infrared photography with the Olympus E-510 digital camera
Blue channel

Provided you set Live View Boost from the camera menu you will, with the R72 filter attached, get a view that is adequate for framing. It is monochrome (or at least so close that it looks that way in the field), but it is bright enough that, provided you adequately shade the LCD from the light, you can setup your shots properly. This is a great gain for IR photography with an unconverted camera and Olympus is the only one whose Live View mode can do this.

Infrared photography with the Olympus E-510 digital camera

The E-510 makes an excellent IR camera unconverted. Exposures can be fairly shot, noise is well controlled and the results can be great. Plus you have a Live View that works well enough in infrared for framing.

Infrared photography with the Olympus E-510 digital camera

A RAW IR image is available for you to download from our IR sample images page.
